Description
| Vertical conveying distance | 10m |
| Horizontal conveying distance | 20m |
| Bare metal weight | 180kg/packed 200kg |
| Motor power | main motor 4kw/air pump motor 2.2kw |
| Maximum mortar ratio | 1:3 |
| Mortar delivery volume | 1.5m³ |
| Working efficiency | 100²/h |
| Hopper volume | 60L |
| Dimensions | 1300×450×750mm (length, width and height) |
| Packing size | 1530×530×1100mm (length, width and height) |
| Barrel inner diameter | 32mm |
| Working pressure | 3-6Map |
| Voltage | 380v/220v |
| Maximum passing particle | 5mm |
| Scope of application | mortar putty coating, etc. |
